NSUI-3008M0A
SKU
242370
Gigabit Switch Industrial, Unmanaged, 8x PoE, 2xSFP, 30W each Port, -40°C~75°C, 44~57 VDC
Main Features
8 RJ45 ports with 10/100/1000 Mbps
2 Gigabit SFP port for fiber optic uplink
8 PoE+ ports, each with up to 30W power
Total PoE power: up to 120 watts
Supports IEEE 802.3af/at standards
Silent operation thanks to fanless design
High EMC protection level
Plug-and-play, no configuration, easy to use.
Redundant power supply 44-57VDC
Robust IP30 housing, DIN-RAIL or wall mounting
Operating temperature range: -40-75°C
Power supply not included
Buy now
You will be redirected to our shop on Videor.com for purchase.
More Information
- Other
- Brand
- ENEO
- Multicast compliant
- no
- Port mirror
- no
- QoS
- no
- SNMP
- no
- Ethernet standards
- IEEE 802.3 10BaseT, IEEE 802.3u 100BaseTX, IEEE 802.3x Flow Control, IEEE 802.3af Power Over Ethernet (PoE), IEEE 802.3at Power Over Ethernet (PoE+)
- Internal switching capacity (Mpps)
- 14,88Mpps
- Internal switching capacity (Gbit/s)
- 20 Gbps
- VLAN
- no
- Ethernet interface
- 1000Base-T, 100Base-TX, 10Base-T
- Ports
- 2x 1000Mbps SFP, 8x 10/100/1000Mbps
- Optical connector
- SFP Port
- Series
- eneo Switch
- Dimensions (HxWxD)
- 50x149,2x122mm
- Weight
- 1,168kg
- PoE ports (number)
- 8
- Construction
- DIN rail module
- Type
- Unmanaged
- Power consumption
- 120W
- Blower
- no
- Management
- no
- Mounting
- DIN rail, wall mount
- PoE budget
- 120 W
- Power over Ethernet
- IEEE 802.3af, IEEE 802.3at
- Supply voltage
- 44~57 VDC
- Operating temperature
- -40°C ~ +75°C, @ Humidity 10%-90% (non-condensing)
- Parts supplied
- manual, 1x DIN Rail
- Remarks
- Power supply unit is not included in the scope of delivery, To achieve the specified PoE budget (total) value, an appropriate optional power supply unit must be used.
- Trunk
- IEC61000-4-2, IEC61000-4-5
- Manufacturer order number
- 242370
Downloads
- Data sheet PDF
- Data sheet with specifications generated live from the product database
- Documents PDF
- Quick reference guide for this product
- Documents PDF
- Kurz-Betriebsanleitung zum Produkt
- Documents PDF
- Declaration of Conformity in German and English
- Media ZIP
- Product Image in a high resolution for print
- Marketing Infos PDF | 109.3 kB
- SFP compatibility overview regarding the eneo switches
- Marketing Infos PDF | 178.1 kB
- NDAA konforme Produkte
