IAD-5SG1004MUC
SKU
237369
Gigabit Switch, Unmanaged, 60W, 4x PoE, 1x RJ45, 1x SFP, 10/100/1000 Mbps, Desktop
Main Features
Gigabit PoE switch, desktop application
4x 10/100/1000 PoE+ ports, IEEE 802.3af/at
Gigabit uplink ports: 1x RJ45, 1x SFP
Up to 30W per port, total ≤60W.
Overvoltage protection IEC61000-4-5 (6KV).
Temperature range (operation) -5°C~45°C
CCTV mode enables transmission up to 250m @10Mbps
CCTV mode supports PoE watchdog function
Plug and Play, no settings required
Metal housing
Buy now
You will be redirected to our shop on Videor.com for purchase.
More Information
- Functions:
- Multicast compliant
- no
- Port mirror
- no
- QoS
- no
- SNMP
- no
- Security
- CCTV Mode
- Network:
- Ethernet standards
- IEEE 802.3 10BaseT, IEEE 802.3u 100BaseTX, IEEE 802.ab 1000BaseT, IEEE 802.3x Flow Control, IEEE 802.3at Power Over Ethernet (PoE+), IEEE 802.3af Power Over Ethernet (PoE)
- Internal switching capacity (Mpps)
- 8,9 Mpps
- Internal switching capacity (Gbit/s)
- 12 Gbps
- VLAN
- no
- Interfaces / Inputs/ Outputs:
- Ethernet interface
- 1000Base-T, 100Base-TX, 10Base-T
- Ports
- 1x 10/100/1000Base-T, 1x 1000Base-X SFP, 4x 10/100/1000Base-T (PoE)
- General:
- Brand
- ENEO
- Dimensions (HxWxD)
- 27x135x86mm
- Weight
- 300g
- PoE ports (number)
- 4
- Construction
- Desktop
- Type
- Unmanaged
- Power consumption
- 65W
- Blower
- no
- Management
- no
- Mounting
- desktop
- PoE budget
- 60 W
- Power over Ethernet
- IEEE 802.3af, IEEE 802.3at
- Supply voltage
- 48~57 VDC
- Operating temperature
- -5°C ~ +45°C
- Application
- indoor
- Trunk
- IEC61000-4-2, IEC61000-4-3, IEC61000-4-4, IEC61000-4-5, IEC61000-4-6, Contact discharge 6KV, Air discharge 8KV
- Parts supplied:
- Parts supplied
- manual, power cord, Mounting Bracket, PSU
- Notes:
- Model
- Desktop
- Manufacturer order number
- 237369
