Mainfeatures
- 1/2,7" CMOS Image Sensor
- Resolution max. 2592x1920
- Multisignal: HD-TVI, AHD, CVI, CVBS
- Fixed 3.6mm day & night lens
- Removable infrared cut filter
- 2D/-3D-DNR noise reduction
- Digital Wide Dynamic Range (D-WDR), Defog
- LDC function(Lens Distortion Correction)
- OSD menu control and signal switching possible via joystick in the cable feed
- Compact housing for outdoor IP66
Specifications
| Camera: | |
| Camera type | Dome |
| Sensor size | 1/2.7" |
| Imager | CMOS, SmartSens, SC5235 |
| System | True Day&Night |
| Sensitivity | 0,05 Lux, at F2.0, 50 IRE, at F1.6 |
| Low speed shutter | no |
| Manual electronic shutter (MES) | 1/15 ~ 1/50.000sec.. |
| Automatic electronic shutter (ESC) | 1/15 ~ 1/50.000sec. |
| Wide Dynamic Range (WDR) | D-WDR |
| Flickerless function | yes |
| Backlight compensation | no |
| Day/Night switching | auto, day, night |
| IR cut filter | switchable |
| White balance | automatic |
| Signal-to-noise ratio | 50dB |
| Video: | |
| Signal format | Composite (FBAS), HD-TVI @ 5MP, AHD @ 5MP, CVI @ 4MP |
| Frame rate | 20fps @ 2592x1944p, 25/30fps @ 2560x1440p |
| Synchronization | internal |
| Lens: | |
| Lens type | fixed focal length |
| Focal length | 3,6 mm |
| Digital zoom | no |
| MOD (Minimum object distance) | 0,2 m |
| Aperture range (F) | F2.0 |
| Resolution pixels | 2592x1944, 2560x1440 |
| Vertical angle of view | 47 ° |
| Horizontal angle of view | 87,4 ° |
| Video standard | PAL/NTSC |
| DORI: | |
| Detection (25 px/m) | 70 m |
| Observation (62 px/m) | 29 m |
| Recognition (125 px/m) | 14 m |
| Identification (250 px/m) | 6 m |
| Features: | |
| Motion detector | no |
| Menu languages | German, English, French, Italian, Spanish, Turkish, Dutch, Portugese, Polish, Chinese, Russian |
| Privacy zones masking | no |
| Mirror function | mirror, V flip, rotation |
| Digital Noise Reduction (DNR) | yes |
| Interfaces / Inputs / Outputs: | |
| Video outputs | HD-TVI, AHD, CVI, composite (CVBS) |
| External connections | video (BNC), 12VDC power input |
| Alarm inputs | no |
| Alarm outputs | no |
| Serial interfaces | Coaxitron (HD Protocol) |
| Serial interfaces protocols | TVI-UTC |
| General: | |
| Series | EX-Series, eneo COAXIZE |
| Dimensions (HxWxD) | 85x90mm |
| Illumination | infrared, 18x LED 850nm |
| Illumination range | approx. 20m |
| Colour (housing) | RAL9016 |
| Colour (bubble) | clear |
| Housing | outdoor |
| Housing material | aluminium |
| Weight | 360g |
| Heater | no |
| Power consumption | 3,7W |
| Blower | no |
| Mounting | wall mount, ceiling mount |
| Protection rating | IP66 |
| Supply voltage | 12VDC |
| Temperature range (operation) | -20°C ~ +50°C |
| Text display | supplied |
| Vandalism resistant | no |
| Scope of delivery: | |
| Parts supplied | manuals, bag of screws |
| Notes: | |
