Mainfeatures
- 1/1,7" Sony STARVIS CMOS-Sensor
- 8.0MP 3840x2160 Pixel, 25/30fps
- 30x AF Zoom, 6~180mm
- Quad Stream H.265, H.264, MJPEG (Smart Codec)
- Real time WDR (Wide Dynamic Range) 25/30fps
- Intelligent self learning video analysis (IntelliVision Technology Inside)
- Digital Noise Reduction (2DNR/3DNR)
- Audio support including audio alarm
- Infrared illumination up to 200m
- Alarm in- and outputs, micro SD-card
- Power supply 12VDC or UPoE (High-PoE Midspan included)
- Support ONVIF Profile S und Profile T
Specifications
| Camera type | PTZ |
| Camera: | |
| Resolution standard | 4K Ultra HD |
| Imager | CMOS, Sony STARVIS, Sensor IMX226 |
| System | True Day&Night |
| Sensitivity | 0,75 Lux, at F1.6, 50 IRE |
| Low speed shutter | yes, automatic |
| Manual electronic shutter (MES) | 1~1/20.000sec. |
| Automatic electronic shutter (ESC) | 1~1/20.000sec. |
| Wide Dynamic Range (WDR) | WDR 120dB |
| Backlight compensation | Smart BLC |
| Day/Night switching | day, night, auto |
| IR cut filter | switchable |
| White balance | automatic, manual |
| Signal-to-noise ratio | 52db |
| Video: | |
| Resolution | 3840x2160 (16:9), 3072x2048 (4:3), 2592x1944 (4:3), 2592x1520 (16:9), 2560x1440 (16:9), 1920x1080 (16:9), 1440x1080 (4:3), 1280x1024 (5:4), 1024x768 (4:3), 1280x720 (16:9), 800x600 (4:3), 800x480 (16:9), 704x576 (4:3), 704x480 (4:3), 640x480 (4:3), 400x240 (4:3), 352x288 (4:3), 352x256 (4:3), 352:240 (4:3), 320x240 (4:3) |
| Resolution max. | 3840x2160 |
| Stream types | Quad Streaming |
| Image transmission rate max. | 30 fps |
| Compression standard | H.264, H.265, H.264+, H.265+, M-JPEG |
| Lens: | |
| Lens type | auto focus zoom |
| Zoom factor | 30x |
| Focal length | 6 - 180 mm |
| Digital zoom | yes |
| MOD (Minimum object distance) | 5 m |
| Iris control | DC |
| Vertical angle of view | 31,1 - 1,5 ° |
| Horizontal angle of view | 55,4 - 2,7 ° |
| DORI: | |
| Detection (25 px/m) | 140 - 3000 m |
| Observation (62 px/m) | 58 - 1300 m |
| Recognition (125 px/m) | 29 - 640 m |
| Identification (250 px/m) | 14 - 300 m |
| Features: | |
| Multicast compliant | yes |
| Motion detector | yes |
| Analysis functions | activity detection, motion analysis, tampering protection, Trip wire plus object counting, loitering detection, intrusion, Human detector, Defog |
| Alarm processing | recording internal storage, E-Mail, FTP, Boost, HTTP, TCP, UDP, HTTPS, XML, alarm out |
| Presets | 256 presets |
| Patterns | 8 pattern |
| Home position | selectable, Tour, Preset, Pattern |
| Tours | up to 8 user programmable guard tours |
| Rotation range | 360 ° |
| Speed (manual control) | 380 °/Sek. |
| Preset speed | 380 °/Sek. |
| Vertical tilt range | -10° ~ +90° |
| Audio | 2 Way Audio |
| Audio support | yes |
| Password protection | yes |
| Internal storage | microSDHC card, microSDXC card |
| Menu languages | English, German, French, Russian, Japanese, Chinese, Korean |
| Privacy zones masking | Areas-ON/OFF switchable |
| Remote configuration | web browser |
| Web browser | MS internet Explorer: ActiveX ex 9.0, Safari: MJPEG setup limited, Mozilla: MJPEG setup limited, Google: MJPEG setup limted, Edge: MJPEG setup limited |
| User interface | Type B (white / blue) |
| Mirror function | H/V flip |
| Digital Noise Reduction (DNR) | yes |
| Network: | |
| Network protocols | TCP/IP, UDP, IPv4, IPv6, HTTP, HTTPS, FTP, UPnP, RTP, RTSP, RTCP, DHCP, ARP, Zeroconf, Bonjour, QoS, OpenVPN |
| Interfaces / Inputs / Outputs: | |
| Video outputs | no |
| External connections | alarm output, alarm input, audio input/output, RJ-45, 12VDC input (DC plug), connection cable approx.40cm |
| Ethernet interface | 10Base-T, 100Base-TX |
| Alarm inputs | 4 |
| Alarm outputs | 1 |
| Serial interfaces | Ethernet |
| General: | |
| Series | eneo SN-Series |
| Dimensions (HxWxD) | 317,8x201.8mm |
| Illumination | infrared, Zoоm Synchronized & Fixed IR LED |
| Illumination range | approx. 200m |
| Colour (housing) | white, black |
| Housing | outdoor |
| Housing material | aluminium |
| Weight | 5.1kg |
| Heater | no |
| Power consumption | 28W |
| Blower | yes |
| Mounting | wall mount, ceiling mount |
| ONVIF | ONVIF Profile S, ONVIF Profile T |
| Protection rating | IP66 |
| SDK | upon request |
| Supply voltage | HiPoE+, 12VDC |
| Temperature range (operation) | -30°C ~ +55°C |
| Text display | supplied |
| Vandalism resistant | no |
| Scope of delivery: | |
| Parts supplied | manual, eneo Site Manager, HiPoE+ Midspan (Power 100-240VAC, Operation Temperature 0°~40°), plug set |
| Notes: | |
| Remarks | To ensure a faultless PoE operation, please use only the supplied HiPoE+ Midspan of accessories pack. |
