IPP-72A0030M0A
This article is no longer available
SKU
213541
1/2.8" Network Dome, PTZ, 30x AF Zoom, Day&Night, 1920x1080, PoE, IP66, 12/24V
Main Features
1/2.8" Sony CMOS-Sensor
30x AF Zoom, 4.3~129mm / 16x Digital
Full HD 1920x1080 pixels, 1080p@50/60fps
Compression H.264/MJPEG, Web Casting
Digital Noise Reduction (DNR)
VCA Video Analytic
Real time WDR (Wide Dynamic Range) 25/30fps
Digital Image Stabilization (DIS)
Privacy zones
Alarm in- and outputs
ONVIF conformity
Buy now
You will be redirected to our shop on Videor.com for purchase.
More Information
- Camera:
- Camera type
- PTZ
- Sensor size
- 1/2.8"
- Resolution Standard
- HD 1080p
- Imager
- Sony STARVIS, Sensor IMX291, CMOS
- Sensitivity
- 0,35 Lux at F1,6, 50 IRE
- System
- True Day&Night
- Low speed shutter
- 2x ~ 8x, yes
- Manual electronic shutter (MES)
- 1/25 ~ 1/30.000sec
- Automatic electronic shutter (ESC)
- 1/25 ~ 1/30.000sec.
- Wide Dynamic Range (WDR)
- Real Time WDR 25/30fps, WDR 120dB
- Flickerless function
- yes
- Backlight compensation
- BLC, HLC
- Day&Night switch
- ICR
- Day&Night mode
- Day, Night, Automatic
- White balance
- Automatic, Outdoor, Manual, fluorescent, Light bulb
- Video:
- Resolution
- 1920x1080 (16:9), 1280x1024 (5:4), 1280x960 (4:3), 1280x720 (16:9), 1024x768 (4:3), 704x576 (4:3), 704x480 (4:3), 640x480 (4:3), 640x360 (16:9), 320x240 (4:3)
- Image resolution max.
- 1920x1080
- Image display
- 4:3, 16:9, 5:4
- Stream types
- 2x H.264, 1x MJPEG multiple
- Image Transmission Rate
- 60 fps
- Video compression
- H.264, M-JPEG
- Lens:
- Lens Type
- auto focus zoom
- Zoom Factor
- 30x
- Focal Length
- 4,3 - 129,0 mm
- Digital Zoom
- 16x
- MOD (Mininum Object Distance)
- 1 m
- Iris Control
- DC
- Functions:
- Multicast compliant
- yes
- Motion detector
- yes
- Analysis functions
- Defog, Face recognition, Field detection, Motion detection, Tampering protection, Trip wire plus object counting
- Alarm processing
- recording internal storage (SD card), E-Mail, FTP, Boost, HTTP, TCP, UDP, HTTPS, XML, alarm out
- Presets
- 255 presets
- Pattern
- 8 Abfahrten
- Home position
- selectable, Tour, Preset, Pattern
- Tours
- up to 8 user programmable guard tours
- Rotation range
- 360°
- Speed (manual)
- 380°/Sek.
- Vertical tilt range
- -10° ~ +90°
- Audio support
- yes
- Audio
- 2 Way Audio
- Password protection
- administrator & users
- Internal storage
- microSDHC card, microSDXC card
- Menu languages
- English, German, French, Russian, Japanese, Chinese, Korean
- Privacy zone masking
- Areas-ON/OFF switchable
- Remote configuration
- Browser
- Web browser
- MS internet Explorer: ActiveX ex 9.0, Safari: MJPEG setup limited, Mozilla: MJPEG setup limited, Google: MJPEG setup limted, Edge: MJPEG setup limited
- User interface
- Type B (white / blue)
- Mirror function
- H-flip
- Digital Noise Reduction
- yes
- Digital noise reduction (DNR)
- yes
- Network:
- Network protocols
- TCP/IP, UDP, IPv4, IPv6, HTTP, HTTPS, FTP, UPnP, RTP, RTSP, RTCP, DHCP, ARP, Zeroconf, Bonjour, QoS, OpenVPN
- Interfaces / Inputs/ Outputs:
- External connectors
- 12VDC input (DC plug), RJ-45, Alarm in/output, Audio input/output, connection cable approx.25cm
- Ethernet interface
- 100Base-TX, 10Base-T
- Alarm inputs
- 4
- Alarm outputs
- 1
- Serial interfaces
- Ethernet
- General:
- Brand
- ENEO
- Series
- eneo SN-Series
- Dimensions (HxWxD)
- 278x234mm
- Weight
- 3.3kg
- Illumination
- no
- Color (housing)
- Pantone Cool Gray 1C
- Color (bubble)
- clear
- Housing
- Outdoor
- Hosuing material
- Aluminium
- Heater
- yes
- Power consumption
- (with heather), 13W, 50W, w./o. heater
- Blower
- yes
- Mounting
- Ceiling mount, Wall mount
- ONVIF
- ONVIF Profile S
- Power over Ethernet
- IEEE 802.3af
- Protection rating
- IP66
- SDK
- upon request
- Supply voltage
- 12VDC, 24VAC, PoE
- Operating temperature
- -50°C ~ +65°C
- Text display
- supplied
- Vandal proof
- yes
- Certifications
- IK10
- Parts supplied:
- Parts supplied
- manual
- Notes:
- Remarks
- Temperature range of -50° ~ +65° are only guaranteed if Dome supplied by 24VAC., In PoE and 12VDC operating heater and fan are disabled
- Special features
- Auto calibration (Origin Check)
- Other
- Imager
- CMOS
- Low Speed Shutter
- yes
- Backlight Compensation
- BLC, HLC
- Wide Dynamic Range (WDR)
- WDR 120dB
- Motion Detector
- yes
- Objektiv Typ
- auto focus zoom
- llumination
- no
- Vertical Angle of View
- 36,4 - 1,29°
- Horizontal Angle of View
- 61,8 - 2,11°
- DORI:
- _headline, _headline
- Detect (25px/m)
- 64 - 2000 m
- Observe (62 px/m)
- 25 - 840 m
- Recognize (125 px/m)
- 12 - 400 m
- Identify (250 px/m)
- 6 - 200 m
- Manufacturer order number
- 213541
