IPD-72A0003M0A
This article is no longer available
SKU
213013
1/3" Network Dome, Fixed, 1920x1080, Day&Night, AF Zoom, WDR, 3-9mm, Infrared, IP67
Main Features
1/3" Panasonic CMOS Sensor
Resolution max. 1920x1080 (Full HD)
Optical 3x Auto Focus Zoom, 16x Digital
3~9 mm day&night zoom lens, IR cut filter
Cross Web Browsing (IE, Safari, Firefox, Chrome)
Responsive Web Design, Zero configuration
Triple Streaming: 2x H.264, 1x MJPEG
VerticalView 90°/270° mode only H.264, HTML5 Playback
Real time WDR (Wide Dynamic Range) 25/30fps
Slot for Micro SD card
ONVIF conformity, PoE IEEE802.af
Hard Coated Bubble, scratch resistant
Buy now
You will be redirected to our shop on Videor.com for purchase.
More Information
- Camera:
- Camera type
- Dome
- Sensor size
- 1/3"
- Resolution Standard
- HD 1080p, HD 720p
- Imager
- Panasonic, MN34229PLI, 2MP Sensor, CMOS
- Sensitivity
- 0,35 Lux at F1,2, 40 IRE
- System
- True Day&Night
- Low speed shutter
- yes
- Manual electronic shutter (MES)
- 1/25~1/60000sec.
- Automatic electronic shutter (ESC)
- 1/25 ~ 1/60.000sec.
- Wide Dynamic Range (WDR)
- Real Time WDR 25/30fps, WDR 113dB
- Flickerless function
- yes
- Backlight compensation
- BLC, HLC
- Day&Night switch
- ICR
- Day&Night mode
- Automatic, Day, Night, extern (Sensor), night-color mode, IR-LED OFF
- White balance
- Automatic, ATW, Manual
- Signal-to-noise ratio
- 50dB
- Video:
- Resolution
- 1920x1080 (16:9), 1280x720 (16:9), 1600x900 (16:9), 640x360 (16:9), 960x540 (16:9), 320x180 (16:9)
- Image resolution max.
- 1920x1080
- Stream types
- 2x H.264, 1x MJPEG multiple
- Image Transmission Rate
- 30 fps
- Video compression
- H.264, M-JPEG
- Lens:
- Lens Type
- auto focus zoom
- Zoom Factor
- 3x
- Focal Length
- 3 - 9 mm
- Digital Zoom
- 16x
- MOD (Mininum Object Distance)
- 0,5 m
- Iris Control
- DC
- Functions:
- Multicast compliant
- yes
- Motion detector
- yes
- Analysis functions
- Cross Counting (CC), Defog, Motion detection, Perimeter Intrusion Detection (PID), Tampering Detection (TD)
- Alarm processing
- recording internal storage (SD card), E-Mail, FTP, Boost, HTTP, TCP, UDP, Onvif Event Mapping, alarm out
- Vertical tilt range
- 65 °(25 ~ 90°)
- Audio support
- yes
- Audio
- 2 Way Audio
- Password protection
- administrator & users
- e-PTZ support
- yes
- Internal storage
- microSDHC card, microSDXC card
- Menu languages
- English, German, French, Polish, Finnish
- Privacy zone masking
- Areas-ON/OFF switchable
- Remote configuration
- Browser
- Web browser
- MS internet Explorer: ActiveX ex 9.0, Safari: MJPEG, Mozilla: MJPEG, Google Chrome: MJPEG, Edge: MJPEG
- User interface
- Type A (orange / grey)
- Mirror function
- mirror, flip
- Digital Noise Reduction
- yes
- Network:
- Network protocols
- TCP/IP, UDP, IPv4, IPv6, HTTP, HTTPS, FTP, UPnP, RTP, RTSP, RTCP, DHCP, ARP, Zeroconf, Bonjour
- Interfaces / Inputs/ Outputs:
- Video outputs
- no
- External connectors
- RJ-45, Combi connector, micro SD card slot, connection cable approx.15cm
- Ethernet interface
- 100Base-TX, 10Base-T
- Alarm inputs
- 1
- Alarm outputs
- 1
- Serial interfaces
- Ethernet
- General:
- Brand
- ENEO
- Series
- eneo KN-Series
- Dimensions (HxWxD)
- 119x140mm
- Weight
- 1 kg
- Illumination
- 2x High Power LEDs 850nm, Infrared
- Illumination range
- approx. 40m
- Color (housing)
- Pantone Cool Gray 1C
- Color (bubble)
- clear
- Housing
- Outdoor
- Hosuing material
- Aluminium
- Heater
- yes
- Power consumption
- 9W
- Blower
- yes
- Mounting
- Ceiling mount, Wall mount
- ONVIF
- ONVIF Profile S
- Power over Ethernet
- IEEE 802.3af
- Protection rating
- IP67
- SDK
- upon request
- Supply voltage
- 12VDC, 24VAC, PoE
- Operating temperature
- -50°C ~ +50°C
- Text display
- supplied
- Vandal proof
- yes
- Certifications
- IK10
- Parts supplied:
- Parts supplied
- manual, bag of screws
- Notes:
- Remarks
- Operating temperature range of the camera changes when IR illumination is switched OFF
- Special features
- Preset Zoom (4 adjustable positions), Smart IR technology: Automatically adjusts the IR illuminance to the ambient conditions
- Other
- Imager
- CMOS
- Low Speed Shutter
- yes
- Backlight Compensation
- BLC, HLC
- Wide Dynamic Range (WDR)
- WDR 113dB
- Motion Detector
- yes
- llumination
- Infrared
- Vertical Angle of View
- 50 - 18°
- Horizontal Angle of View
- 90 - 32°
- Manufacturer order number
- 213013
