eneo INM-78M2812M0A
Main Features
More Information
- Manufacturer order number
- 236668
- Brand
- ENEO
- EAN/GTIN
- 4260229840627
- Series
- eneo IN-Serie
Camera
- Camera shape
- Minsters
- Chip size
- 1/1,8"
- Resolution standard
- 32 MP
- Recording sensor
- CMOS
- Photosensitivity
- 0,006 Lux bei F1,2
- System
- Electronic Day&Night
- Low Speed Shutter
- Yes
- Manual Electric Shutter (MES)
- 1-5~1-20,000sec.
- Backlight compensation
- Yes
- Day/night switching
- Switchable IR Filter (ICR)
- Day/night mode
- Day,Night,Automatic,Time
- White balance
- Automatic
- Signal-to-noise ratio
- 51 dB
Video
- Resolution (extended)
- 3840x2140 (16:9),2592x1944 (4:3),2592x1520 (16:9),2304x1296 (16:9),1920x1080 (16:9),1280x960 (4:3),1280x720 (16:9),640x480 (4:3),320x240 (4:3)
- Video Compression
- H.264, H.264+, H.265, H.265+, M-JPEG
- Data stream types
- Triple-Stream(Main/Sub/Mobile)
- Image transfer rate max.
- 25 fps
Lens
- Lens Type
- Varifocal (motorized)
- Focal length
- 2,8 - 12 mm
- MOD (Minimum Object Distance)
- 0 m
- Aperture Range (F)
- F1.3
- Vertical angle of view
- 27 - 58°
- Horizontal angle of view
- 360°
Display
- Image resolution max.
- 4x 3840x2160
DORI
- Perceiving (25px/m)
- 58,6 - 177 m
- Watch (62px/m)
- 23,4 - 71 m
- Detect (125px/m)
- 11,4 - 35,1 m
- Identify (250px/m)
- 5,4 - 17,6 m
Functions
- Multicast
- Yes
- Motion detector
- Yes
- Analysis
- Abandoned and Removed Objects (SOD), Attendance (FA), Crowds (CD), Face Attributes (AD), Face Capture (FD), Face Recognition (FR), Heat Map (HM), Intrusion (PID), Leave Region, License plate recognition (LPD), License plate recognition (LPR), Line crossing (LCD), Object Classification Human / Vehicle (PD&VD), Passage count (CC), Queues (QD), Rare Sounds (RSD)
- Alarm processing
- recording internal storage (SD card),E-Mail,HTTP,FTP,TCP,UDP,alarm out,Cloud Upload
- Audio support
- Yes
- Audio
- 2 Way Audio
- Password
- Administrator and User
- Internal memory
- 256GB, microSD card, microSDHC card, microSDXC card
- Menu languages
- English, French, German, Italian, Japanese, Portuguese, Russian, Spanish, Turkish
- Browser
- Firefox, Google Chrome, MS Internet Explorer 10/11, Safari
- Digital Noise Reduction (DNR)
- Yes
- Privacy Zone
- Areas-ON/OFF switchable
Network
- Network Protocols
- DDNS, DHCP, DNA, FTP, HTTP, HTTPS, IEE 802.1, NTP, PPPoE, RTP, RTSP, SMTP, TCP-IP, UPnP
Interfaces / Inputs/ Outputs
- External connections
- RJ-45,12VDC input,24VAC input,Alarm in/output,Audio input/output,micro SD card slot 256 GB
- Alarm inputs
- 0
- Control Interfaces
- Ethernet
General
- Wide Dynamic Range (WDR)
- WDR 120dB
- Lighting
- Infrared, White
- Dimensions (WxHxD) (extended)
- 300x195mm
- Weight
- 4.6 kg
- Illumination range
- Approx. 35 m IR , Approx. 25 m White light
- Color (Housing)
- RAL9003,Pantone P 179-1 / Other colors available upon request
- Color (dome)
- clear
- Housing type
- Outside
- Housing material
- Aluminium
- Camera Type
- Multi-sensor camera
- Power consumption
- 43 W
- Mounting type
- Wall
- ONVIF
- ONVIF Profile G, ONVIF Profile M, ONVIF Profile S, ONVIF Profile T
- Power over Ethernet
- IEEE 802.3bt
- ESC
- 1/5 ~ 1/20.000sec.
- Protection
- IP67, NEMA 4X
- SDK
- upon request
- Power supply
- 12VDC, 24VAC, PoE++
- Temperature Range (Operating)
- -30°C ~ +55°C,@ Luftfeuchtigkeit 95% oder weniger (nicht kondensierend)
- Text overlay
- Switchable on/off
- Vandalism-resistant
- Yes
- Certifications
- IK10
Parts supplied
- Scope of delivery
- manual,bag of screws,wall bracket,PoE-Injector 100-240VAC~ 56VDC,60W
Notes
- Remark
- For optimal results,use only eneo components. For mixed brands,we offer a compatibility check for a fee (info: item #229235 at VIDEOR).
Further product information
Application Scenarios for the eneo INM-78M2812M0A Multisensor 360° Camera
The eneo INM-78M2812M0A combines four 4K sensors, advanced video analytics and a rugged outdoor housing to deliver powerful 360° surveillance. It replaces multiple single-sensor cameras, eliminates blind spots and lowers installation and operating costs – the ideal choice for professional video security where image quality, reliable detection and compliance really matter.
Typical use cases:
City and municipal surveillance Monitoring squares, intersections, pedestrian zones or parks with just one camera. The total 32 MP resolution and WDR provide highly detailed images – even in backlight situations and challenging lighting conditions.
Parking lots, garages and outdoor areas Complete overview of large parking areas, entrances/exits and loading zones. Integrated IR and white light illumination ensure clear images at night, while AI analytics support accurate detection of people and vehicles.
Logistics, warehousing and industrial sites Surveillance of loading bays, production areas and warehouses. The rugged, vandal-resistant IK10/IP67 design is made for harsh environments, and object classification helps to minimize false alarms.
Shopping centers, retail areas and branch networks Wide-area coverage of entrances, mall areas and checkout zones. Multiple viewing directions can be combined flexibly – for visitor flow analysis, safety and loss prevention within a single system.
Education and healthcare campuses Monitoring of campus grounds, courtyards, access roads and parking areas. 360° coverage supports security concepts at schools, universities and hospitals with just a few strategically placed cameras.
Critical infrastructure and perimeter protection Securing energy facilities, water plants, data centers or government sites. AI-driven analytics help reliably detect and classify security-relevant events around sensitive areas.
Transport hubs and public transit Use at train and bus stations or airport access roads. The wide dynamic range (120 dB WDR) delivers clear images in scenes with strong contrasts, such as entrances from bright outdoor zones into darker halls.
With PoE&43;&43;, an included wall mount and browser-independent access, the eneo INM-78M2812M0A integrates quickly and easily – into existing VMS platforms via ONVIF as well as into new, modern security architectures.
You can find an installation video at the following link:
https://youtu.be/nXzJc5kh7C4?si&61;TR3gRwAcHbXxwLL5
