eneo INB-58F0002M0PA
Main Features
More Information
- Brand
- ENEO
- EAN/GTIN
- 4260229840610
- Manufacturer order number
- 238642
- Series
- eneo IN-Serie
Camera
- Backlight compensation
- Yes
- Camera shape
- Bullet
- Chip size
- 1/2,8"
- Day/night mode
- Day,Night,Time,night-color mode
- Day/night switching
- Switchable IR Filter (ICR)
- Flickerless function
- On-Off
- Low Speed Shutter
- Yes
- Manual Electric Shutter (MES)
- 1-5~1-20,000sec.
- Photosensitivity
- 0,007 Lux bei F1,0
- Recording sensor
- CMOS, Sony IMX415
- Resolution standard
- 8 MP
- Signal-to-noise ratio
- 44 dB
- System
- True Day&Night
- White balance
- Automatic,Manual
DORI
- Detect (125px/m)
- 5,4 m
- Identify (250px/m)
- 2,6 m
- Perceiving (25px/m)
- 27,3 m
- Watch (62px/m)
- 11,1 m
Lens
- Aperture Range (F)
- F2,4
- Focal length
- 2 mm
- Horizontal angle of view
- 180°
- Lens Type
- Prime lens
- MOD (Minimum Object Distance)
- 0.6 m
- Vertical angle of view
- 91°
Video
- Data stream types
- Triple-Stream(Main/Sub/Mobile)
- Image transfer rate max.
- 20 fps
- Picture size
- 16:9, 4:3
- Resolution (extended)
- 3840x2160 (16:9) @20fps,2592x1944 (4:3),2304x1296 (16:9),1920x1080 (16:9),1280x960 (4:3),1280x720 (16:9),640x480 (4:3)
- Video Compression
- H.264, H.264+, H.265, H.265+, M-JPEG
Display
- Image resolution max.
- 3840x2160
Functions
- Alarm processing
- recording internal storage (SD card),E-Mail,HTTP,FTP,TCP,UDP,alarm out,Cloud Upload,Siren
- Analysis
- Abandoned and Removed Objects (SOD), Attendance (FA), Crowds (CD), Enter Region, Face Attributes (AD), Heat Map (HM), Intrusion, Intrusion (PID), Leave Region, Line crossing (LCD), Manipulation (TD), Object Classification Human / Vehicle (PD&VD), Passage count (CC), Queues (QD), Rare Sounds (RSD)
- Audio
- Built-in microphone, Built-in speaker
- Audio support
- Yes
- Browser
- Edge, Firefox, Google Chrome, Safari
- Digital Noise Reduction (DNR)
- Yes
- Internal memory
- 256GB, microSDHC card, microSDXC card
- Menu languages
- English, French, German, Italian, Japanese, Portuguese, Russian, Spanish, Turkish
- Motion detector
- Yes
- Multicast
- Yes
- Password
- Administrator and User
- Privacy Zone
- Areas-ON/OFF switchable
Network
- Network Protocols
- DDNS, DHCP, DNA, FTP, HTTP, HTTPS, IEE 802.1, NTP, RTP, RTSP, SMTP, TCP-IP, UPnP
- Security
- Complicated password, IP address filtering, Password
Interfaces / Inputs/ Outputs
- Control Interfaces
- Ethernet
- External connections
- RJ-45,12VDC input (DC plug),micro SD card slot 256 GB
General
- Camera Type
- Panoramic camera
- Color (Housing)
- RAL9003,Pantone P 179-1 / Other colors available upon request
- Dimensions (WxHxD) (extended)
- 95x241,3mm
- ESC
- 1/5 ~ 1/20.000sec.
- Heating
- No
- Housing material
- Aluminium
- Housing type
- Outside
- Illumination range
- Approx. 25 m Infrared , Approx. 15 m White light
- Integrated wall mount
- Yes
- Lighting
- Infrared, White
- Mounting type
- Ceiling, Wall
- ONVIF
- ONVIF Profile G, ONVIF Profile M, ONVIF Profile S, ONVIF Profile T
- Power consumption
- 12 W
- Power over Ethernet
- IEEE 802.3af
- Power supply
- 12VDC, Poe
- Protection
- IP67, NEMA 4X
- SDK
- upon request
- Sunshade canopy
- Yes
- Temperature Range (Operating)
- -35°C ~ +60°C,@ Luftfeuchtigkeit 90% oder weniger (nicht kondensierend)
- Text overlay
- Switchable on/off
- Weight
- 0.35 kg
- Wide Dynamic Range (WDR)
- WDR 120dB
Parts supplied
- Scope of delivery
- Quick installation guide,drilling template,3x wall plugs with screws,2x Allen wrench,1x waterproof cover for RJ45 connector
Notes
- Remark
- Face and license plate recognition require an SD card or an eneo IN recorder. For optimal results,use only eneo components. For mixed brands,we offer a compatibility check for a fee (info: item #229235 at VIDEOR).
Further product information
Video Clip:
Use Cases:
Entrances & reception areas
Perfect for covering doorways and lobby zones: the 180° panoramic view minimizes blind spots and can reduce the number of cameras required.
Retail – coverage & business insights
Designed for shop floors, checkout areas and promotions: Heat Mapping and People Counting help analyze customer flow and optimize merchandising and staffing.
Parking lots & driveways
Ideal for car parks, gates and access roads: AI human/vehicle classification helps deliver more relevant alarms and reduces false notifications – day and night.
Building perimeter protection
For façades, back doors, yards and loading areas: Line crossing and intrusion detection enable event-driven alerts, while WDR handles challenging backlight scenes.
Warehouses, logistics & loading bays
Great for dock doors and dispatch areas: the combination of ultra-wide coverage and 8MP resolution provides both overview and detail in dynamic lighting.
Outdoor & industrial sites
Built for harsh conditions: IP67 protection and an operating range down to -35°C support reliable year-round outdoor deployment.
Night surveillance with IR and white light
For low-light or unlit areas: integrated IR and white-light LEDs support clear imaging and deterrence depending on the chosen mode.
Unattended sites / edge recording
For branches, remote locations or temporary setups: microSD edge storage enables recording even without a permanent NVR connection.
Audio-enabled security
For entrances and security zones: built-in microphone and speaker enable audio monitoring and live/remote announcements (subject to configuration and local compliance).
