IER-28R160405A

    IER-28R160405A

    Art. No.: 227036

    Network Video Recorder, 16x IP, H.265, 128Mbps, HDMI/ VGA, 16x PoE, 4TB HDD

    Mainfeatures

    • 16-channel network video recorder
    • Easy installation with eneo IP cameras
    • Compression method: H.265
    • Resolution IP cameras up to 8 megapixel
    • Remote Access: Control of additional recorders
    • Memory expandable via iSCSI, POS interface
    • CMS administration software included
    • Smartphone app for video monitoring / configuration
    • 16x alarm input and 1x alarm output
    • 16x PoE port (IEEE802.3af), total power 130W
    • 4K 3840x2160 HDMI / VGA monitor output
    • Supports dewarping for (ISD-55xx/ISD-59xx)

    Specifications

    Video:
    Compression standard H.264, H.265
    Display:
    Playback full screen, 4 channel split, 9 channel split, 16 channel split, sequence
    Live Display 3840x2160, 1920x1080, 1280x720, 1024x768, max. 480fps
    Recording:
    Max. recording resolution 3840x2160
    Recording speed 25 / 30 fps per channel
    Max. recording rate 480 fps
    Recording permanent, timer, movement, contact, panic, PoS-Text, event
    Pre-alarm recording up to 5sec.
    Backup Setup
    Export of images or clip USB-port external HDD, via client software, AVI, H4V, MP4 via eneo Center
    Features:
    Motion detector integrated
    Analysis functions motion detection
    Alarm notification e-mail notification, alarm output, remote software, Live Popup, Buzzer, PTZ Preset, FTP, Push (Mobile)
    Alarm triggers disk error, eystem error, video loss, motion detection, PoS-Text, contact
    Audio support yes
    Password protection user control
    HDD hotswap no
    Menu languages English, German, French, Italian, Dutch, Chinese
    Remote access remote software, iPhone, Android, WEB Browser (Java)
    Search function date/time, event, Thumbnail, text, museum, Instant Playback, VCA search
    Covert camera mode yes
    GDPR functions Four-eye principle, Defined storage times per channel, Differentiated authorisation management, Detailed log informations, Password cycle, Menu logout during inactivity, NAT/IPC isolation of PoE camera ports, Full encrypted WAN, -
    Network:
    Network 1x 10/100/1000 Base-T RJ45
    Network connection WAN 1 x 10/100/1000BASE-T, 16x PoE RJ45 10/100 Base-T
    Network protocols TCP/IP, DHCP, Zeroconf, IPv4, IPv6, HTTP, UPnP, ARP, SMTP, RTSP, RTP, FTP, NTP
    Data transfer rate 416 Mbps
    Data transfer incoming 128 Mbps
    Data transfer outgoing 288 Mbps
    Interfaces / Inputs / Outputs:
    IP channels 16
    Monitor outputs HDMI (4K), VGA
    Spot monitor no
    USB ports 2x USB 2.0, 1x USB 3.0
    Interfaces external storage iSCSI, Maximal capacity 96TB, Intern: 2x HDD up to 28 TB max., 6x iSCSI (16TB lun) max. minus internal HDD capacity
    Interfaces external storage Maximal capacity 96TB, Intern: 2x HDD up to 28 TB max., 6x iSCSI (16TB lun) max. minus internal HDD capacity
    Alarm inputs 16
    Alarm output 1
    Audio output line output, HDMI
    Serial interfaces RS-485
    System requirements:
    Operation system Linux
    General:
    Series eneo IE-Series, Safe & Easy
    Dimensions (HxWxD) 44,9x375x318,2mm
    19" Rack mountable yes
    Number of HHD slots 2x SATA
    Control units (external) mouse
    Harddisk capacity (internal) 4 TB
    Max. harddisk capacity (internal) 28 TB
    Weight 2.3kg
    Integrated writer no
    Power consumption 150W
    Remote Software eneo Center
    ONVIF yes
    PoE Power 130 W
    Power over Ethernet IEEE 802.3af, IEEE 802.3at
    RAID n/a
    Supply voltage 100-230VAC, 50/60Hz
    Temperature range (operation) 0°C ~ +45°C
    Scope of delivery:
    Parts supplied remote viewer software, PSU, manual, HDD assembly-kit, mouse, 19" rack mount angle
    Notes:
    Remarks IP cameras of the PXB, PXC, PXD and PTB series are not supported by this product
    Firmware update via remote software, USB

    Special features

    ADUP (Archive Dual User Permission): dual authentication to access search, playback and backup. Users of this feature should have administrator rights., Remote Access: Function for control and remote configuration of additional recorders, live and playback image display corresponds to Stream 2
