    IEB-72M2812MCA

    Art. No.: 220932

    1/2,8" Network Camera, 1920x1080,Day&Night , WDR, 2,8-12mm, EPOC, IR, IP66

    Mainfeatures

    • 1/2,8" Sony STARVIS CMOS
    • Resolution max. 1920x1080, 25fps frame rate
    • Motorised vary focal lens 2,8~12mm with P-Iris
    • EPOC Ethernet and Power over Coax transmission
    • Wide Dynamic Range, T-WDR (120dB)
    • Intelligent self learning video analysis (IntelliVision Technology Inside)
    • Quad Streaming: H.264, H.265 x3, MJPEG x1, Smart Codec
    • Micro SD Card (SDHC, SDXC)
    • 1 x Alarm in and output as well as audio support
    • Infrared illumination up to 30m
    • Easy installation, IP66, PoE IEEE 802.3af
    • Support ONVIF Profile S and Profile T

    Specifications

    Camera type Bullet
    Camera:
    Sensor size 1/2.8"
    Resolution standard HD 1080p
    Imager CMOS, Sony STARVIS, Sensor IMX290
    System True Day&Night
    Sensitivity 0,03 Lux, at F1.6, 40IRE
    Low speed shutter yes, automatic
    Manual electronic shutter (MES) 1~1/10000Sek.
    Automatic electronic shutter (ESC) 1~1/10.000sec.
    Wide Dynamic Range (WDR) WDR 120dB
    Flickerless function yes
    Backlight compensation Smart BLC
    Day/Night switching day, night, auto
    IR cut filter switchable
    White balance automatic, manual
    Video:
    Resolution 1920x1080 (16:9), 1440x1080 (4:3), 1280x1024 (5:4), 1024x768 (4:3), 1280x720 (16:9), 800x600 (4:3), 800x480 (16:9), 704x576 (4:3), 704x480 (4:3), 640x480 (4:3), 400x240 (4:3), 352x288 (4:3), 352x256 (4:3), 352:240 (4:3), 320x240 (4:3)
    Resolution max. 1920x1080
    Stream types Quad Streaming
    Image transmission rate max. 30 fps
    Compression standard H.264, H.265, H.264+, H.265+, M-JPEG
    Lens:
    Lens type Varifocal (motorized)
    Focal length 2,8 - 12 mm
    Digital zoom yes
    MOD (Minimum object distance) 0,5 m
    Iris control P-iris
    Vertical angle of view 56 - 18 °
    Horizontal angle of view 100 - 33 °
    DORI:
    Detection (25 px/m) 40 - 130 m
    Observation (62 px/m) 16 - 55 m
    Recognition (125 px/m) 8 - 26 m
    Identification (250 px/m) 4 - 13 m
    Features:
    Multicast compliant yes
    Motion detector yes
    Analysis functions activity detection, motion analysis, tampering protection, Trip wire plus object counting, loitering detection, intrusion, Human detector
    Alarm processing recording internal storage, E-Mail, FTP, Boost, HTTP, TCP, UDP, HTTPS, XML, alarm out, Alarm Forwarding (Preset Call of eneo PTZ Dome)
    Audio 2 Way Audio
    Audio support yes
    Password protection yes
    e-PTZ support yes
    Internal storage microSDHC card, microSDXC card
    Menu languages English, German, French, Russian, Chinese, Korean, Japanese
    Privacy zones masking Areas-ON/OFF switchable
    Remote configuration web browser
    Web browser MS internet Explorer: ActiveX ex 9.0, Safari: MJPEG setup limited, Mozilla: MJPEG setup limited, Google: MJPEG setup limted, Edge: MJPEG setup limited
    User interface Type B (white / blue)
    Mirror function H-flip, mirror
    Digital Noise Reduction (DNR) yes
    Network:
    Network protocols TCP/IP, UDP, IPv4, IPv6, HTTP, HTTPS, FTP, RTP, UPnP, RTSP, RTCP, DHCP, ARP, Zeroconf, Bonjour, QoS, OpenVPN
    Interfaces / Inputs / Outputs:
    External connections BNC - EPOC, audio input/output, alarm output, alarm input, 12VDC input (DC plug), connection cable approx.40cm
    Alarm inputs 1
    Alarm outputs 1
    Serial interfaces Ethernet
    General:
    Series eneo EPOC, eneo EN-Series
    Dimensions (HxWxD) 86x90x279mm
    Illumination infrared, 34x LED 850nm
    Illumination range approx. 30m
    Colour (housing) white
    Housing outdoor
    Housing material aluminium
    Weight 1,03kg
    Integrated wall mount yes
    Power consumption 9W
    Blower no
    Mounting wall mount, ceiling mount
    ONVIF ONVIF Profile S, ONVIF Profile T
    Window heater no
    Protection rating IP66
    SDK upon request
    Hidden cable management yes
    Sunshield yes
    Supply voltage 12VDC
    Temperature range (operation) -20°C ~ +50°C
    Text display supplied
    Vandalism resistant no
    Scope of delivery:
    Parts supplied manual, eneo Site Manager, bag of screws
    Notes:
    Remarks Note that electronic adjustment aid such as Zoom / Focus or Pan / Tilt functions are not designed for continuous operation. Permanent use may affect the life of the camera
