IEB-64M2812M0A
1/3" Network Camera, Day&Night, 2592x1520, H.265, Infrared, 2.8-12mm, PoE, IP66
This article is no longer available
Art. No.
218032
- 1/3" Omnivision CMOS sensor
- Megapixel varifocal lens, motorized, 2.8~12mm
- Resolution max. 2592x1520
- Compression H.265/ H.264/ MJPEG
- Cross-Web-Browsing
- ROI (Region of interest)Hi-Stream to reduce the bandwidth
- Tampering, Defog
- D-WDR (Digital Wide Dynamic Range)
- Framerate increase on motion detection
- Compact design, Outdoor applications, IP66
| Series | eneo EN-Series, Safe & Easy |
|---|---|
| Camera: | |
| Camera type | Bullet |
| Sensor size | 1/3" |
| Resolution Standard | 4 Megapixel |
| Imager | CMOS, OmniVision Sensor 4689 |
| System | True Day&Night |
| Sensitivity | 0,1 Lux, bei F2,1, 50 IRE |
| Low Speed Shutter | yes |
| Low speed shutter | automatic |
| Manual electronic shutter (MES) | 1~1/20.000sec. |
| Automatic electronic shutter (ESC) | 1~1/20.000sec. |
| Wide Dynamic Range (WDR) | D-WDR |
| Backlight Compensation | BLC |
| Day&Night switch | ICR |
| Day&Night mode | day, night, auto |
| White balance | automatic, manual |
| Signal-to-noise ratio | 50dB |
| Video: | |
| Resolution | 2 Megapixel Modus @ 30fps, 4 Megapixel Mode @20fps, 2592x1520 (16:9), 1920x1080 (16:9), 1280x1024 (5:4), 1280x720 (16:9), 1024x768 (4:3), 704x576 (4:3), 704x480 (4:3), 640x480 (4:3), 320x240 (4:3) |
| Image resolution max. | 2592x1520 |
| Image display | VerticalView 90°/270°, 4:3, 16:9, 5:4 |
| Stream types | 1x H.265, 1x H.264, 1x MJPEG multiple |
| Image Transmission Rate | 30 fps |
| Video compression | H.264, H.265, H.264+ (Smart Stream), H.265+ (Smart Stream), M-JPEG |
| Lens: | |
| Lens Type | Varifocal (motorized) |
| Zoom Factor | 4x |
| Focal Length | 2,8 - 12 mm |
| MOD (Mininum Object Distance) | 0,3 m |
| Iris Control | DC |
| Vertical Angle of View | 52 - 20° |
| Horizontal Angle of View | 94 - 34° |
| DORI: | |
| Detect (25px/m) | 64 - 155 m |
| Observe (62 px/m) | 25 - 65 m |
| Recognize (125 px/m) | 12 - 33 m |
| Identify (250 px/m) | 5 - 15 m |
| Functions: | |
| Multicast compliant | yes |
| Motion Detector | yes |
| Analysis functions | motion analysis, intrusion, tampering protection, Defog |
| Alarm processing | E-Mail, FTP, Boost, HTTP, TCP, UDP, HTTPS, XML |
| Audio support | no |
| Password protection | administrator & users |
| e-PTZ support | yes |
| Internal storage | no |
| Menu languages | English, German, French, Russian, Chinese, Korean, Japanese |
| Privacy zone masking | Areas-ON/OFF switchable |
| Remote configuration | web browser |
| Web browser | MS internet Explorer: ActiveX ex 9.0, Safari: MJPEG setup limited, Mozilla: MJPEG setup limited, Google: MJPEG setup limted, Edge: MJPEG setup limited |
| User interface | Type B (white / blue) |
| Mirror function | H-flip, mirror |
| Digital Noise Reduction | yes |
| Network: | |
| Network protocols | TCP/IP, UDP, IPv4, IPv6, HTTP, HTTPS, FTP, UPnP, RTP, RTSP, RTCP, DHCP, ARP, Zeroconf, Bonjour, QoS, OpenVPN |
| Interfaces / Inputs/ Outputs: | |
| Video outputs | no |
| External connectors | RJ-45, 12VDC input (DC plug), connection cable approx.40cm |
| Ethernet interface | 10Base-T, 100Base-TX |
| Alarm inputs | no |
| Alarm outputs | no |
| Serial interfaces | Ethernet |
| General: | |
| Dimensions (HxWxD) | 82x81x239mm |
| Weight | 680g |
| llumination | infrared |
| Illumination | 30x LED 850nm |
| Illumination range | approx. 30m |
| Color (housing) | white |
| Housing | outdoor |
| Hosuing material | aluminium |
| Integrated wall mount | yes |
| Power consumption | 7W |
| Blower | yes |
| Mounting | wall mount, ceiling mount |
| ONVIF | ONVIF Profile S, ONVIF Profile T |
| Power over Ethernet | IEEE 802.3af |
| Protection rating | IP66 |
| SDK | upon request |
| Sunshield | yes |
| Supply voltage | PoE, 12VDC |
| Operating temperature | -20°C ~ +50°C |
| Text display | supplied |
| Vandal proof | no |
| Parts supplied: | |
| Parts supplied | manual, bag of screws |
