Manufacturer order number

230801

Brand

ENEO

Series

eneo Candid Small,eneo AN-Serie

Camera

Camera shape

Bullet

Chip size

1/2,8"

Resolution standard

2 MP

Recording sensor

CMOS

Photosensitivity

0,0008 Lux bei F1,6,40 IRE

System

True Day&Night

Low Speed Shutter

Yes

Flickerless function

Yes

Backlight compensation

Yes

Day/night switching

Switchable IR Filter (ICR)

Day/night mode

Automatic,Day,Night,extern (Sensor)

White balance

Automatic,Outdoor,Light bulb,Fluorescent light,Clear Sky,Shade,Manual

Signal-to-noise ratio

50 dB

Video

Resolution (extended)

1920x1080 (16:9),1280x720 (16:9)

Video Compression

H.264, H.264+, H.265, H.265+, M-JPEG

Data stream types

Multi-Streaming

Image transfer rate max.

30 fps

Lens

Lens Type

Varifocal (motorized)

Focal length

2,7 - 13,5 mm

Zoom Factor (Digital)

0

MOD (Minimum Object Distance)

0.5 m

Vertical angle of view

56 - 18°

Horizontal angle of view

108 - 32°

Zoomfactor (optical)

4

Display

Image resolution max.

1920x1080

DORI

Perceiving (25px/m)

30,6 - 116,4 m

Watch (62px/m)

11,9 - 46,6 m

Detect (125px/m)

5,5 - 23,1 m

Identify (250px/m)

2,9 - 11,4 m

Functions

Multicast

Yes

Motion detector

Yes

Analysis

Manipulation (TD), Motion Detection

Alarm processing

recording internal storage (SD card),E-Mail,HTTP,FTP,Boost,TCP,UDP,Onvif Event Mapping,alarm out

Audio support

No

Password

Administrator and User

Internal memory

microSDHC card, microSDXC card

Menu languages

English, French, German, Korean

Browser

Edge: MJPEG, Mozilla: MJPEG, Safari: MJPEG

Digital Noise Reduction (DNR)

Yes

Interfaces / Inputs/ Outputs

External connections

micro SD card slot,Connection board (LSA,RJ45,audio,I / O alarm & Sabotage contacts)

Alarm inputs

1

Control Interfaces

Ethernet

General

Wide Dynamic Range (WDR)

D-WDR

Lighting

Infrared

Dimensions (WxHxD) (extended)

130,50x82,15x265,80mm

Weight

1.25 kg

Color (Housing)

Pantone Cool Gray 1C

Housing type

Outside

Housing material

Aluminium

Integrated wall mount

Yes

Power consumption

8 W

Mounting type

Ceiling, Wall

ONVIF

ONVIF Profile S, ONVIF Profile T

Power over Ethernet

IEEE 802.3af

Protection

IP67

SDK

upon request

Sunshade canopy

Yes

Power supply

Poe

Temperature Range (Operating)

-50°C ~ +50°C

Text overlay

available

Parts supplied

Scope of delivery

manual,bag of screws

Notes

Remark

NDAA compliance under Section 889,To guarantee you an optimum user experience,we recommend that you only use components of the same brand in a system. If several brands are used in combination,eneo cannot guarantee functionality. If combined use is necess
