IAM-6MC1001MTA

Ethernet Coax Transmitter Data & Power over Coax 1 x RJ-45, 1 x BNC
Art. No.
221576
  • EPOC Ethernet and Power over Coax Transmission
  • RJ45 Ethernet and BNC-Female plug
  • Max. Transmission Rate 95Mbps Full Duplex
  • Data Transmission up to 2.4Km
  • PoC Transmission up to 1.2Km
  • Power Supply Transmitter PoE or 12-57V DC
  • PoE Power Supply for Camera
  • 128 Bit AES Network Encryption
  • Supports Multi Connection (Daisy Chain, Star)
  • Surge Protection
  • Temperature Range (Operating) -20° C bis +60°C
  • Easy Installation (Plug & Play)
Special features
Network transmission with 128bit AES encryption standard
Specifications
Series eneo EPOC
Network:
Data tranfer rate max. 95 Mbps
Interfaces / Inputs/ Outputs:
External connectors RJ-45 (max. 60W PoE out), BNC - EPOC, 56VDC input (DC plug)
Ethernet interface 10Base-T, 100Base-TX
General:
Dimensions (HxWxD) 24x61,6x82,4mm
Weight 77g
Model module
Colour anthracite
Housing Metal
Power consumption max. 60W
Supply voltage 56VDC, Power over Coax (PoC)
Operating temperature -20°C ~ +60°C
Parts supplied manual
