MPB-72M2713M0A
1/2.8" HD Camera, Day&Night, 1920x1080, Infrared, WDR, 2.7-13.5mm, 12/24V, IP67
Art. No.
217277
- 1/2.8" 2 Megapixel SONY STARVIS CMOS sensor
- Resolution max. 1920x1080 pixels (Full HD)
- Separate outputs for digital and multi-signal
- Multisignal: HD-TVI, AHD, CVI and Composite selectable
- Digital signal: EX-SDI, HD-SDI selectable
- Motorized lens 2.7 ~ 13.5mm
- Removable infrared cut filter
- ROI (Region of Interest) WDR mode
- Integrated motion detector, defog, privacy zones
- IP67, built heater
- Easy installation, central locking screw
- IR illumination switchable via OSD menu
| Series | eneo KX-Series, eneo COAXIZE, eneo Candid Medium |
|---|---|
| Camera: | |
| Camera type | Bullet |
| Sensor size | 1/2.8" |
| Imager | CMOS, Sony STARVIS, Sensor IMX291 |
| System | True Day&Night |
| Sensitivity | 0,08 Lux, at F1.4, 40IRE |
| Low Speed Shutter | yes |
| Low speed shutter | manual time preselection |
| Manual electronic shutter (MES) | 1/25 ~ 1/30.000sec |
| Automatic electronic shutter (ESC) | 1/25 ~ 1/30.000sec. |
| Wide Dynamic Range (WDR) | WDR 113dB, Real Time WDR 25/30fps |
| Flickerless function | yes |
| Backlight Compensation | BLC, HLC |
| Day&Night switch | ICR |
| Day&Night mode | Automatic, Day, Night |
| White balance | Automatic, Preset, Manual |
| Signal-to-noise ratio | 50dB |
| Video: | |
| Signal format | Composite (FBAS), HD-TVI @ 2MP, AHD @ 2MP, CVI @ 2MP, EX-SDI (270 Mbps), HD-SDI (1.485 Gbps) |
| Frame rate | 25/30fps @ 1920x1080p, 50/60fps @ 1280x720p |
| Synchronization | internal |
| Lens: | |
| Lens Type | Varifocal (motorized) |
| Zoom Factor | 4x |
| Focal Length | 2,7 - 13,5 mm |
| Digital Zoom | no |
| MOD (Mininum Object Distance) | 0,5 m |
| Aperture range (F) | F1.4 |
| Iris Control | DC |
| Resolution Pixels | 1920x1080, 1280x720, 720x576 |
| Vertical Angle of View | 53 - 19° |
| Horizontal Angle of View | 100 - 38° |
| Video standard | PAL/NTSC |
| DORI: | |
| Detect (25px/m) | 47 - 128 m |
| Observe (62 px/m) | 18 - 52 m |
| Recognize (125 px/m) | 8 - 25 m |
| Identify (250 px/m) | 4 - 12 m |
| Functions: | |
| Motion Detector | yes |
| Analysis functions | Defog |
| OSD function control | OSD camera setup |
| Menu languages | German, English, Chinese, Japanese, Korean |
| Privacy zone masking | Areas-ON/OFF switchable |
| Mirror function | mirror, V flip |
| Digital Noise Reduction | yes |
| Interfaces / Inputs/ Outputs: | |
| Video outputs | HD-TVI, AHD, CVI, composite (CVBS), EX-SDI, HD-SDI |
| External connectors | voltage input, 1x SDI Signal (BNC), 1x HD/SD Analog Signal (BNC), connection cable approx.100cm |
| Alarm inputs | no |
| Alarm outputs | no |
| Serial interfaces | Coaxitron (HD Protocol) |
| Serial interfaces protocols | UTC (HD-Signal Format) |
| General: | |
| Dimensions (HxWxD) | 100x107,8x277mm |
| Weight | 1.35kg |
| llumination | infrared |
| Illumination | 5x High Power LEDs 850nm |
| Illumination range | approx. 60m |
| Color (housing) | Pantone Cool Gray 1C |
| Housing | Outdoor |
| Hosuing material | Aluminium |
| Heater | yes |
| Integrated wall mount | yes |
| Power consumption | 10.5W |
| Mounting | Wall mount, Ceiling mount |
| Protection rating | IP67 |
| Sunshield | yes |
| Supply voltage | 12VDC, 24VAC |
| Operating temperature | -30°C ~ +50°C |
| Text display | supplied |
| Vandal proof | no |
| Parts supplied: | |
| Parts supplied | manual, drilling template, bag of screws |
| Remarks | NDAA compliance under Section 889, Part A. |
